Dahua IPC-HFW7442H-Z-X 4MP WizMind X IR Bullet Camera

IPC-HFW7442H-Z-X is a 4 MP IR bullet from the Dahua WizMind X series, built for scenes that need analytics rather than just pictures. It runs ANPR, face recognition, PPE detection, people counting and parking space management on the camera, can run two intelligent functions at once, and records at up to 50/60 fps at 2688 x 1520.

An analytics bullet for gates, car parks and PPE checkpoints

The datasheet describes a Time-Division Exposure function that keeps snapshot quality when several targets appear together, and ANPR that recognises plate, vehicle logo, type and colour for vehicles moving up to 60 km/h, with 10,000 blocklist and 10,000 allowlist records. Face recognition supports five face databases and up to 200,000 face pictures, and PPE detection checks workwear, hat, mask, gloves, boots, seatbelt and safety vest.

The motorized 2.7 to 12 mm lens at F1.2 covers 107 to 48 degrees horizontal. DORI figures are 60.4 m detect at wide and 128.7 m detect at tele. Eight GB of ROM and 4 GB of RAM host the analytics, and five streams are available.

Key features from the Dahua datasheet

• 4 MP 1/1.8 inch sensor, 2688 x 1520 at 50/60 fps, 150 dB WDR
• Motorized vari-focal 2.7 to 12 mm, F1.2, P-Iris
• Four IR LEDs up to 60 m; operating range to +65 C
• ANPR, face recognition, PPE detection, people counting, parking management, privacy protection
• 12 VDC, 24 VAC, PoE+ or ePoE; gigabit port, BNC output, 1 TB micro SD

Technical specification

Camera and lens

Video and intelligence

Interfaces, power and environment

Selection and ordering guide

The datasheet lists DH-IPC-HFW7442H-Z-X as 4MP IR Bullet WizMind Network Camera. Moderate anti-corrosion protection is stated for the -ATC model only, and NEMA Type 4X is marked optional, so state the variant you need in the enquiry.

Choose this model when the task is ANPR, PPE or face matching; the WizSense 2 and 3 cameras in the Dahua range list perimeter and motion analytics but not these functions on their datasheets (derived comparison).

Installation and operation notes

The camera accepts 12 VDC, 24 VAC and PoE+. Dahua lists the PFA154 pole bracket and PFM900-E mount tester. For ANPR, face recognition and PPE, set camera height, angle and exposure to the manual guidance; the datasheet refers to the installation and commissioning manual and project design tool for intelligent function distances. Web access supports Chrome, Firefox and IE11, and management is through SmartPSS Lite, DSS or DMSS.

Applications in Oman and the GCC

Typical uses are factory and plant gates with plate capture, contractor induction points that check helmets and vests, car parks with space counting, and retail entrances with people counting. The -40 to +65 C operating range and IK10 suit exposed mounting; the optional coating and NEMA 4X variant are relevant for washdown or coastal exposure.

Selection and installation notes

A security camera is selected from the scene, the distance, the light level and the analytics needed. Plan the mounting height and angle, the PoE or power supply, the cable run and the storage for the number of recording days required, set a strong password at commissioning and keep the firmware current. Check the coverage at night as well as in daylight.

Information needed for a quotation

Send the full model code, the quantity, the delivery location in Oman or the GCC, the intended use and any accessories needed, so that the complete package can be quoted together.

Documents and supply information

The manufacturer data sheet is attached to this page and should be read together with the project specification and the site risk assessment before a purchase is confirmed. Ratings, standards and dimensions are quoted as printed on that sheet. Lead time, stock position and certificates available with the shipment are confirmed in the quotation, and we supply to Oman and the wider GCC region for industrial, utility and building services projects.

Compatible accessories and related items

Datasheet accessories: PFA154 pole mount bracket, PFM320D 12 VDC 2 A adapter, PFM900-E integrated mount tester and TF-P100 microSD card. Record with a WizMind NVR such as NVR5832RH-XI.

Frequently asked questions

What lens does the IPC-HFW7442H-Z-X use?

A motorized vari-focal 2.7 to 12 mm lens at F1.2 with P-Iris, giving 107 to 48 degrees horizontal field of view.

Can it read licence plates?

Yes, the datasheet lists ANPR with plate, vehicle logo, type and colour, for vehicles up to 60 km/h, with blocklist and allowlist records.

Does it detect helmets and vests?

Yes. PPE detection covers workwear, hat, mask, apron, gloves, shoe covers, boots, seatbelt and safety vest.

What are the power options?

12 VDC, 24 VAC, PoE+ 802.3at or ePoE.

Can Seven Star LLC quote this model?

Yes. We are an independent supplier in Muscat; send the variant and quantity through the quotation form.

Documents and quotation

For a quotation, send your required quantity and destination. The Dahua datasheet for IPC-HFW7442H-Z-X is provided for download on this page. Seven Star LLC works as an independent supplier from Muscat. Please compare code, ratings and options with the document before you place an order; see also the CCTV and security listing.
