CHINT NL1-63 RCCB Residual Current Circuit Breaker
Description
A residual current circuit breaker for people and fire protection
The NL1-63 is a two- or four-pole residual current circuit breaker (RCCB) from CHINT. It has no overcurrent element, so it detects earth leakage and disconnects the circuit, and it must be backed by a miniature circuit breaker or fuse for overload and short-circuit protection. The CHINT catalog lists residual current breakers for housing, the tertiary sector and industry, to protect people against indirect contact, add protection against direct contact and reduce fire risk caused by insulation faults.
Technical specifications
| Parameter | Specification |
|---|---|
| Standard | IEC/EN 61008-1; IEC/EN 62423 is also listed in the catalog |
| Leakage types listed | AC, A, A-G and AC-G (G/SI short delay), A-S and AC-S (selective), F |
| Rated current In | 16, 25, 32, 40, 63 A; 80 and 100 A versions are also listed in the same catalog |
| Poles | 2P and 4P |
| Rated voltage Ue | 230/400 to 240/415 V AC; 110/127 V for 2P |
| Rated sensitivity IDn | 10 mA (2P up to 32 A), 30, 100, 300 and 500 mA |
| Insulation voltage Ui / impulse Uimp | 500 V / 4000 V (1.2/50) |
| Conditional short-circuit current Inc / IDc | 6000 A / 10,000 A; 10,000 A with an SCPD fuse |
| Break time at IDn | 0.1 s or less (normal type); 10 to 300 ms (G/SI); 150 to 500 ms (S type) |
| Electrical / mechanical life | 4,000 / 4,000 operations |
| Dielectric test | 2 kV, 1 minute at industrial frequency; pollution degree 2 |
| Terminals | Cable 25 mm2 top and 35 mm2 bottom; busbar 10 mm2 top and 16 mm2 bottom; 2.5 N.m torque |
| Protection degree | IP20; fault current indicator fitted |
| Ambient temperature | -25 to +70 degC with a daily average of 35 degC or less; storage -25 to +70 degC |
| Mounting | 35 mm DIN rail (EN 60715) with fast clip, feed from top or bottom |
| Weight | 2P 0.27 kg; 4P 0.37 kg |
Choosing the sensitivity, wave form and time delay
The catalog ties each sensitivity to a duty. A 10 mA unit suits precision instrument circuits and bathrooms, 30 mA gives additional protection against direct contact, 100 mA is coordinated with the earthing system using IDn less than 50 divided by the earth resistance, and 300 or 500 mA protects against indirect contact and fire. Choose the wave form next: AC type for slowly rising sinusoidal leakage, type A where pulsed DC residual currents can occur, and the S and G/SI types where filters against spurious tripping from harmonics and transient surges are wanted. The S type provides total discrimination with a non-selective device placed downstream, and the catalog states stable behaviour with an 8/20 us surge of 3000 A.
Ambient temperature reduces the carrying current. For the 16 A frame the catalog allows 16 A at 40 degC, 11 A at 50 degC and 9 A at 55 degC, so a hot enclosure needs a larger frame or better ventilation.
Ordering code and what to confirm
The designation runs frame, poles, current, sensitivity, leakage type, breaking capacity and busbar or accessory suffix. Examples from the catalog are NL1-63 2P 16A 30mA A 6kA DBAX with code 527233 and NL1-63 4P 63A 30mA A 6kA DBAX with code 527342. Confirm the pole count and neutral arrangement, the load current, the required sensitivity, the leakage type and the upstream overcurrent device. A compact alternative that adds overcurrent protection is the
, and other makes are in the circuit breakers category.Documents and quotation
The CHINT NL1 RCCB catalog is attached; every figure in the table comes from it. Send the complete designation, quantity and delivery location through the quotation form for availability from Seven Star LLC.
