Vortice LINEO 200 ES Energy Saving Mixed Flow In-Line Fan 17167

17167 is the Vortice LINEO 200 ES, an energy-saving in-line mixed flow extractor fan for 200 mm ducts. It combines a fire-resistant plastic casing, a thermally protected brushless EC motor with a centrifugal impeller and a speed that can be set from 0 to 10 V, delivering up to 1,100 m3/h at 342 Pa from only 90 W at full speed.

A 200 mm EC in-line fan for quiet, controllable duct extraction

The LINEO range is built for ducted extraction where a straight-through, in-line fan is easier to install than a wall or roof unit. In the 200 mm size the ES (energy saving) version uses an EC motor, so airflow can be trimmed to the real demand instead of being throttled. The technical data sheet lists five speed points, from 2 V (310 m3/h, 6.3 W) to 10 V (1,100 m3/h, 90 W), which makes the power saving at part load easy to read directly.

The casing is moulded in E2 class fire-resistant resin in the zones around the motor and electrics, and the unit is rated IPX5 when installed in a duct. A thermal fuse is built in as an over-temperature safety device. The booklet describes it as an in-line centrifugal extractor fan for residential and commercial properties.

Key features as printed in the datasheet

• EC (brushless) motor, thermally protected, ball-bearing shaft, centrifugal impeller.
• Speed adjustable by a 0-10 V potentiometer signal or by a two-speed switch preset at installation.
• IPX5 water resistance when installed in a duct; electrical protection IP 45; insulation class II.
• Thermal fuse as an over-temperature safety device.
• Fire-resistant E2 class plastic resin around motor and electrical parts (ISO EN 11925-2: 2010).
• Mixed flow range, 50-60 Hz, 220-240 V single phase, 4.6 kg.

Technical specification

Technical data, as printed on the Vortice data sheet

Performance at control voltage steps

Other sizes in the LINEO ES family (Vortice data sheets, values at maximum speed)

Selection and ordering guide

LINEO 200 ES is the point in the range where airflow passes 1,000 m3/h on a 200 mm duct. The 150 ES (590 m3/h) and 160 ES (630 m3/h) suit smaller branches, the 250 ES (1,475 m3/h) and 315 ES (2,625 m3/h) serve main runs. Quiet and Q versions exist for noise-critical rooms: LINEO 200 QUIET ES carries the same airflow class in a sound-proof casing, but at 8.6 kg against 4.6 kg here.

Because the fan is EC-controlled, size to the duty point you need: about 700 m3/h at 141 Pa takes only 25.7 W at the 6 V step according to the data sheet. Check duct pressure loss before ordering.

Installation and operation notes

The booklet requires installation by a qualified electrician, an omnipolar switch with at least 3 mm contact opening, and both inlet and outlet ports connected to duct. The fan must discharge into a single duct dedicated to it, and the room needs adequate replacement air. Maximum operating ambient temperature is 50 C.

Commissioning uses dip-switches: SW1 selects the model (for LINEO 200 ES the booklet shows Int.1 OFF, Int.2 ON, Int.3 OFF, Int.4 ON, set at the factory) and SW2 selects two-speed or adjustable-speed mode. Trickle (V1) and boost (V2) speeds can be trimmed with a potentiometer, and factory values restored by a documented reset. Control accessories must be installed in rooms not above 25 C.

Applications in Oman and the GCC

Ducted extraction for kitchens, washrooms, plant rooms, offices, shops and hotel back-of-house areas where the duct run is short and noise matters. In Gulf buildings with long duty hours the EC speed control reduces energy use during low-occupancy periods.

The booklet excludes use with flammable vapours and exposure to rain or sun.

Compatible accessories and related items

Vortice lists an ON/OFF control box with potentiometer, codes 12826 and 12828, on request for adjustable-speed operation. Other mixed flow variants in the same size class include the Q and QUIET versions.

Frequently asked questions

What airflow does the Vortice LINEO 200 ES deliver?

The data sheet gives 1,100 m3/h (305.6 l/s) at 10 V and 342.3 Pa maximum pressure, falling to 310 m3/h at 2 V.

How is the fan speed controlled?

By a 0-10 V potentiometer signal or by a two-speed switch, as set during installation using the dip-switches described in the booklet.

What is the power consumption?

Maximum absorbed power is 90 W (0.80 A) at 10 V and 6.3 W at the 2 V step.

Is it protected against water?

The description states IPX5 when installed in a duct; the unit is IP 45 with insulation class II.

Is Seven Star LLC a Vortice distributor?

No. Seven Star LLC is an independent supplier in Muscat that sources Vortice products on request.

Documents and quotation

The official Vortice technical data sheet for 17167 is hosted on this page for download. Seven Star LLC is an independent supplier in Muscat; send your quantity and delivery location through the quotation form and we will quote this item. Please confirm the exact order code, ratings and approvals against the document before ordering. More related products: product category.
