Soler & Palau TD-2000/315 SILENT 3V Steel Acoustic Duct Fan

Steel-cased acoustic duct fan for 315 mm duct systems

Unlike the plastic TD-SILENT sizes, the Soler & Palau TD-2000/315 SILENT 3V is built from sheet steel with epoxy polyester paint and an acoustic lining of glass fibre inside the outer shell. It moves up to 1770 m3/h through a 315 mm duct and the datasheet records 39 dB(A) at 3 m on high speed, with the TD-2000 model carrying the Noise Abatement Society certificate of approval.

The fan unit is detachable for maintenance or cleaning without demounting the duct connections, and the terminal box is external (IP55), which keeps the wiring out of the air stream. It targets large-volume quiet extraction or supply in open-plan offices, hotel back-of-house, auditoria and similar spaces served by ducting above a ceiling.

Construction as described by S&P

• Sheet steel casing with epoxy polyester paint; acoustic insulation in glass fibre (M0, A2-s1,d0 as printed on different catalogue pages).
• Aerodynamic inlet to improve airflow and reduce sound.
• Removable fan body with 3-speed motor: single phase 230 V, 50/60 Hz, speed controllable, class F, external rotor aluminium motor with capacitor and thermal protection.
• Body IP44; external terminal box IP55 mounted remote from the body.
• Support bracket for wall or ceiling mounting, with fixing brackets to the motor body included.

Technical specification

Selection notes

The TD-1300/250 SILENT is the smaller steel sibling at 1160 m3/h on its medium point, a 250 mm duct and a 20 kg body; the TD-2000/315 SILENT is the pick for larger airflows or when 315 mm ducting is already in place. At 25 kg and 825 mm long it needs a proper support frame.

The wide temperature window, -40 to +60 degC, is the same as the steel TD-MIXVENT models. Use the catalogue curves to check that the system pressure drop of grilles, bends and attenuators sits within the fan characteristic at the speed you will run.

Installation

S&P calls out three benefits of the 1300 and 2000 design: low profile for ceiling voids, a detachable fan unit, and the IP55 remote terminal box. Verify the supply against the data plate, support the casing from the bracket, wire to the external box and connect ducts. Service access is from the fan unit side, so leave clearance there.

Ordering checklist and control options

Quote the full code TD-2000/315 SILENT 3V. The controllers printed against it are the COM-3 and INTER 4P three-speed switches, the RMB-1,5 auto-transformer controller and the larger REB-2,5 electronic controller; the lower amp rated REB-1 listed for the 200 mm size is not the one printed for this fan.

Mechanical accessories named in the SILENT catalogue for the 1300 and 2000 sizes use the MCA, MAR, MRJ, MPC and MBR series codes with the number 2000. The MCA non-return flap is installed at the fan discharge to prevent heat leakage when the extractor is stopped, the MAR adapter allows connection to 500 x 315 mm rectangular ducting, the MRJ grille protects the fan from foreign objects, and the MPC flow detector measures pressure at the inlet of TD units fitted with an airflow straightener.

• Supply 230 V single phase, 50/60 Hz.
• Duct 315 mm circular.
• Weight 25 kg: specify supports.
• Confirm whether acoustic data at octave bands is needed; the catalogue prints sound power spectra per working point.

Accessories

See the wider range of HVAC and ventilation equipment.

Installation and selection notes

The acoustic lining and detachable fan unit allow cleaning without disturbing the ductwork, so leave an access panel or clear space beneath the unit. Support the steel casing from the structure rather than the duct, wire the external IP55 terminal box with a cable gland suited to the cable, and confirm the speed settings against the airflow needed after commissioning.

Information needed for a quotation

Send the full model code, the quantity, the supply voltage and phase, the delivery location in Oman or the GCC and any accessories such as controllers, silencers, dampers or flexible connectors, so that the complete package can be quoted together.

Documents and supply information

The manufacturer data sheet is attached to this page and should be read together with the project specification before a purchase is confirmed. Airflow, pressure, sound and motor values are quoted as printed on that sheet. Lead time, stock position and certificates available with the shipment are confirmed in the quotation, and we supply to Oman and the wider GCC region for industrial, utility and building services projects.

Frequently asked questions

How much air can the TD-2000/315 SILENT 3V deliver? 1770 m3/h on high speed, with 1610 and 1480 m3/h on medium and low.

Is the terminal box IP rated? Yes, the external terminal box is printed as IP55, while the body is IP44.

What is the casing made of? Sheet steel with epoxy polyester paint and glass fibre acoustic insulation.

Is it single phase? Yes, single phase 230 V, 50/60 Hz, class F motor with capacitor and thermal protection.

Is Seven Star LLC the manufacturer? No. Seven Star LLC is an independent supplier in Muscat; confirm the exact model, voltage and options before ordering.
