Sauter VKAI032F300 DN32 Cut-Off Ball Valve Rp 1-1/4 PN40

The VKAI032F300 is a DN 32 two-way cut-off ball valve from Sauter with a Rp 1¼ female thread and a nominal pressure of 40 bar. It is a quarter-turn on/off valve for heating, ventilation and air-conditioning circuits, paired with Sauter rotary actuators, and it combines a very low leakage rate with a compact brass body weighing 700 g.

A tight shut-off valve for two-position duty

Where a coil, zone or heat-pump loop only has to be fully open or fully closed, a ball valve costs less space and torque than a globe valve. Sauter positions the VKAI as both a cut-off device and a control unit for 2-point control. The ball is chrome-plated and polished DZR brass, seated on PTFE collars that are backed by EPDM O-rings; the datasheet explains that these O-rings let the ball and collars move slightly in the axial direction, giving tightness with small torque. The stated leakage rate is 0.0001 times the Kvs value, and with the AKM115SF152 actuator the valve can cut off in six seconds.

Key features from the datasheet

• Female thread to ISO 7/1 Rp, body in dezincification-resistant moulded brass (EN 12165)
• Nominal pressure 40 bar, angle of rotation 90°
• Delivered rotated 90° clockwise; A to AB is 100 % open and 0 % in the closed position
• Spindle sealed by two EPDM O-rings; low torque from the collar mounted on an O-ring
• Strainer and brass screw fittings are available as accessories
• Not approved for drinking water; not suitable for potentially explosive atmospheres

Technical specification

Selection and ordering guide

Order codes combine VKAI, the nominal size and F300. Other sizes are separate orders.

For DN 32 the datasheet gives Δpmax of 1.8 bar with the AKM105 (4 Nm), 3.5 bar with the AKM115 family (8 Nm; AKM115SF152 7 Nm), and 3.5 bar Δpmax with Δps 5.4 bar using the spring-return AKF112 and AKF113 (7 Nm). Spring-return versions give a defined position on power failure. The values apply with Sauter actuators only.

Installation and operation notes

• The actuator mounts directly with a bayonet connector; on commissioning a SUT actuator drives to the end position, joins the spindle automatically and learns the rotation angle.
• To keep the ball from sticking, a SUT actuator makes an approx. 30° movement when the positioning signal has not changed for three days.
• Use in closed circuits only; high oxygen content can destroy the ball valve in open circuits. Water quality to VDI 2035, glycol 20 % to 50 %.
• Fit dirt filters, for example one per floor or pipe run, to protect the PTFE collar.
• Fit in any position but not hanging; keep condensate and drips out of the actuator; leave the actuator flange uninsulated.
• A hand crank on the AKM actuators engages when the manual knob is pushed down.

Applications in Gulf building services

Ball valves with a 40 bar rating are widely used in GCC chilled-water and heating-water plant for isolating fan-coil banks, AHU coils and heat-pump or chiller branches where a binary decision is enough. The brass-and-PTFE construction suits treated closed-loop water, and the 130 °C limit covers hot-water service. Because condensation is not permitted on the valve, insulate pipework and keep the actuator in a ventilated, dry location.

Selection and installation notes

A ball valve is selected from the nominal size, the thread type, the pressure rating and the medium temperature. Check the actuator compatibility, fit the valve with the flow direction and the orientation shown in the instructions, flush the pipework before installation and use suitable thread sealant. Test the shut-off after commissioning.

Information needed for a quotation

Send the full model code, the quantity, the delivery location in Oman or the GCC, the intended use and any accessories needed, so that the complete package can be quoted together.

Documents and supply information

The manufacturer data sheet is attached to this page and should be read together with the project specification and the site risk assessment before a purchase is confirmed. Ratings, standards and dimensions are quoted as printed on that sheet. Lead time, stock position and certificates available with the shipment are confirmed in the quotation, and we supply to Oman and the wider GCC region for industrial, utility and building services projects.

Accessories and related items

Frequently asked questions

What actuators fit the VKAI032F300?

Sauter lists AKM 105(S), 115(S), 115SA and the spring-return AKF 112 and 113(S) rotary actuators for the VKAI range.

What is the leakage rate?

The datasheet gives 0.0001 x Kvs, which for a Kvs of 35 m³/h is a derived figure of 0.0035 m³/h.

Can I use it on open circuits?

No. Sauter states that ball valves must be used in closed circuits only because excess oxygen can destroy them.

Is it approved for drinking water or explosive atmospheres?

No. The datasheet says the VKAI has no drinking-water approval and is not suitable for potentially explosive atmospheres.

Who supplies the VKAI032F300 in Oman?

Seven Star LLC is an independent supplier in Muscat and quotes against the exact order code; confirm actuator, voltage and accessories before ordering.

Documents and quotation

The official Fr. Sauter AG product data sheet 8.1 56.096 (edition 2023) is linked on this page. Send the order code, quantity and application to request a quotation. See more in Hydraulic Valves & Components.
