FITOK PVSS-FL2-02 2-Way Plug Valve, 1/8 in. FITOK Tube

PVSS-FL2-02 is a FITOK PV Series quarter-turn plug valve in 316 stainless steel with 1/8 in. FITOK tube fitting ends. The product page lists 3,000 psig (207 bar) between -10 F and 400 F (-23 C and 204 C), a 0.09 in. (2.4 mm) orifice, Cv 0.1 and an FKM O-ring.

The smallest on-off valve in the range

A plug valve turns a tapered or cylindrical plug through a quarter turn to open or close a cross hole. In a size of 1/8 in. it gives a very compact shut-off for sampling and gauge lines. The overall length is 1.99 in. (50.5 mm) and the second dimension is 0.98 in. (24.9 mm), which is smaller than most ball valves with the same tube connection.

In the code, PV is the plug valve series, SS is 316 stainless steel, FL2 is the 1/8 in. FITOK tube end, and 02 is the 2-way flow pattern code. The catalog covers sizes from 1/8 in. to 3/4 in. and from 6 mm to 12 mm.

Points from the catalog

• Quarter-turn operation with position visible from the handle.
• 3,000 psig working pressure for this code.
• FKM O-ring seal; suitable for many hydrocarbons and oils.
• Optional downstream vent version rated 150 psig (10.3 bar).

Technical specification

Specification of PVSS-FL2-02

Plug valve compared with ball and needle valves

A plug valve is the right choice when space is short and the pressure is moderate, and when only on and off positions are needed. A needle valve gives finer flow adjustment; a ball valve usually has a higher Cv. At Cv 0.1 this valve suits very small flows such as analyzer sample lines.

Mind the flow direction. The catalog says that reverse flow is limited to a differential pressure of 150 psig and that throttling in the reverse direction may damage the O-ring. If back flow can happen at higher differential pressure, add a check valve.

The temperature range is narrower than for the NG needle valve of the same maker. Confirm that the process stays inside -10 F to 400 F.

Use and care

Operate the valve fully open or fully closed. A partly open plug exposes the O-ring to a high-velocity stream and shortens its life.

Do not exceed the stated pressure when the valve is closed against a cold line that may warm up, as trapped liquid can expand and raise pressure beyond the rating.

Before ordering, write down the tube outside diameter, the wall thickness and the fluid. A 1/8 in. valve is easily blocked by particles, so fit a small filter upstream when the fluid is not clean. For liquids, confirm that the viscosity allows flow through a 0.09 in. orifice at the available pressure drop, because Cv 0.1 passes only a small volume per minute.

After installation, pressure test the connections with an inert gas or liquid at the test pressure given in your plant procedure, and tag the valve with its code so that spare seals can be identified quickly.

GCC applications

General engineering note: small plug valves are used on gas chromatograph sample lines, calibration gas supplies, pressure gauge isolation and chemical dosing panels in oil, gas, power and water treatment plants. The 316 stainless steel body resists corrosion in humid coastal air. Verify fluid compatibility and certification needs before ordering.

Related FITOK items

Other FITOK catalogs list ball valves, needle valves and check valves in matching tube sizes. Stainless steel tubing and fittings can be quoted with the valve.

Frequently asked questions

What is the pressure and temperature rating?

3,000 psig (207 bar) between -10 F and 400 F (-23 C and 204 C).

Can the valve handle reverse flow?

Only up to 150 psig differential pressure; throttling reverse flow may damage the O-ring.

What does FL2 mean in the code?

FL2 is the 1/8 in. FITOK tube fitting end.

Which sizes does the PV series cover?

The catalog lists sizes from 1/8 in. to 3/4 in. and from 6 mm to 12 mm.

Is Seven Star LLC a FITOK distributor?

No. Seven Star LLC is not a FITOK distributor; it is an independent Muscat-based supplier that quotes FITOK products on request.

Documents and quotation

This page carries the official FITOK datasheet and manual for PVSS-FL2-02. Seven Star LLC is an independent supplier in Muscat and sources FITOK products on request; tell us the quantity and delivery point to receive a quotation. Always confirm the order code and technical values in the documents first. See more in the product category.
