Alicat M-2000SLPM Gas Mass Flow Meter 2000 SLPM

The Alicat M-2000SLPM is a gas mass flow meter with a 2000 SLPM full scale, part of the high-flow M/MB-Series sheet that runs from 50 to 12,000 SLPM. At 2000 SLPM the sheet gives a 5.0 PSID pressure drop, 3/4 inch NPT female ports, a 5.20 x 2.90 x 5.29 inch body and a weight of about 4.5 lb (2.0 kg).

A high-flow laminar DP meter for plant-scale gas lines

The M-Series uses a laminar flow element with on-board absolute pressure and temperature sensing, so one instrument reports mass flow, volumetric flow, pressure and temperature. The 2000 SLPM size sits in the middle of the high-flow range, between 1000 SLPM (6.0 PSID) and 3000 SLPM (7.1 PSID), with the same 0.8 % of reading plus 0.2 % of full scale accuracy.

The high-accuracy option is limited to models up to 500 SLPM, so the 2000 SLPM unit is a standard-accuracy device. Flow range is 0.01 to 100 % of full scale (10,000:1 turndown), and the meter holds 98 NIST-based gas property tables plus 20 mixes.

Key features as printed in the datasheet

• Full scale 2000 SLPM; pressure drop 5.0 PSID venting air.
• Accuracy 0.8 % of reading + 0.2 % of full scale; repeatability 0.2 % + 0.02 %.
• Operating pressure 11.5 to 160 PSIA; temperature -10 to 60 degC.
• Sensor response under 1 ms; indication response under 10 ms; update 40 Hz digital, 1 kHz analog.
• 98 stored gases and 20 COMPOSER mixes.

Technical specification

Performance data (M/MB-Series, 50 to 12,000 SLPM sheet)

Mechanical and electrical data

Selection and ordering guide

Choose the size so that normal flow falls in the upper part of the range for best accuracy; neighbouring sizes on the sheet are 1000, 3000 and 5000 SLPM. If pressure drop is critical, Alicat points to its WHISPER MW range, which this site also lists as MW-500SLPM.

Alicat offers a portable MB-Series version of the same meter with a rechargeable battery and Bluetooth Low Energy; the MB-2000SLPM top-level number exists on the Alicat page. Analog outputs are not available on MB units.

Compressed-air audits and compressor acceptance tests are typical uses: the meter gives mass flow normalised to standard conditions, so comparisons between sites at different altitudes and temperatures remain consistent. The reference conditions are user configurable, with 25 degC and 1 atm as the default standard, so you should confirm which reference your specification uses before comparing against another instrument.

Installation and operation notes

The Alicat M-series manual says no straight runs of pipe are required upstream or downstream and the meter works in any position because it is internally compensated for orientation. Use in-line sintered filters of no more than 50 microns where pressure drop allows.

Ensure the pipework can handle the 5.0 PSID drop, and avoid rapid pressure changes above 75 PSI differential.

Applications in Oman and the GCC

High-flow M-Series meters measure compressed air, nitrogen and process gases on utility headers, purge systems, gas-burner test stands and compressor performance tests. Confirm gas compatibility with the stainless steel and FKM wetted parts listed above.

Compatible accessories and related items

See also the MC-100SLPM controller and the MW-500SLPM WHISPER meter on this site.

Frequently asked questions

What flow range does the M-2000SLPM measure?

Up to 2000 SLPM full scale, with a 10,000:1 measurement range from 0.01 to 100 %.

What is the pressure drop?

5.0 PSID at full scale when venting air to atmosphere.

Can it have the high-accuracy option?

No; the sheet limits it to models of 500 SLPM and below.

What process connection is standard?

3/4 inch NPT female.

Is Seven Star LLC an ALICAT distributor?

No. Seven Star LLC is not an ALICAT distributor; it is an independent Muscat-based supplier that quotes ALICAT products on request.

Documents and quotation

Need M-2000SLPM? The ALICAT datasheet is attached to this listing. Seven Star LLC (independent supplier, Muscat) can quote the item and arrange supply on request; list quantity and site location in your enquiry. Verify the code, dimensions and approvals in the document before ordering. Other products are in the category page.
