Autonics E40S6-2500-6-L-5 Rotary Encoder Incremental

Product Overview

The Autonics E40S6-2500-6-L-5 encoder is an incremental rotary encoder from the Autonics E40S series, a compact and reliable encoder family widely used in industrial automation. This model provides 2500 pulses per revolution (PPR), giving high resolution feedback for position and speed control applications.

The encoder features a 6 mm shaft and operates with a 5 V DC supply, generating two square wave output channels in quadrature (A and B) for direction detection, plus an index (Z) pulse per revolution. Its robust construction and sealed design make it suitable for demanding industrial environments.

Key Features

• Incremental rotary encoder with 2500 pulses per revolution
• 6 mm shaft diameter version
• 5 V DC supply voltage
• Quadrature outputs (A, B) with index pulse (Z)
• High resolution for accurate position and speed feedback
• Compact E40S series housing for space saving installation
• Robust construction for industrial environments

Technical Specifications

Applications

The E40S6 encoder is used for position, speed and direction measurement in CNC machines, servo drives, conveyors, packaging machinery, elevators, robots and factory automation equipment.

Ordering and Selection

When ordering the Autonics E40S6-2500-6-L-5 encoder, confirm the resolution, shaft size, supply voltage and output type, because the Autonics E40S6 encoder series covers many incremental configurations. The Autonics E40S6-2500-6-L-5 provides 2500 pulses per revolution on a 6 mm shaft with 5 V DC supply, and the open collector output of the Autonics E40S6-2500-6-L-5 must be matched to the receiving controller input. Our team can help you confirm that the Autonics E40S6-2500-6-L-5 you select is correct for your drive or measuring application.

Maintenance and Support

The Autonics E40S6-2500-6-L-5 encoder is a sealed unit requiring no routine maintenance, but the shaft coupling should be inspected periodically. Replacement Autonics E40S6-2500-6-L-5 encoders and other Autonics models are available through Seven Star LLC. Contact our team for assistance with the Autonics E40S6-2500-6-L-5, and we will confirm availability and lead time for your project.

Industry Applications and Custom Support

The Autonics E40S6-2500-6-L-5 encoder is trusted by operations and maintenance teams across factories and automation plants in Oman, the GCC and the wider Middle East region. Our customers select the Autonics E40S6 encoder for reliability, genuine quality and dependable supply. Seven Star LLC provides custom support including technical selection, quotation and after-sales assistance, and we regularly supply this encoder as part of preventive maintenance programs and shutdown packages. Whether you need a single unit or a complete set for a project, our team supports procurement and inspection.

The E40S6-2500-6-L-5 is an incremental rotary encoder with 2500 pulses per revolution, a 6 mm solid shaft and a 5 VDC line driver output stage. The encoder is used for the speed and position measurement on motors, conveyors and machine tools, and the output signals are compatible with the PLC and the counter inputs. The unit is supplied with the standard connector configuration and the mounting bracket option.

The encoder housing is rated for the industrial environment, and the connection uses the standard M12 or cable exit options. The line driver output provides the noise immune signal transmission over the longer cable runs, and the encoder is also available with the complementary output and the various resolutions for the matching application.

The Autonics E40S6 encoder series is used for the position feedback of the machine tools and the speed measurement of the conveyor drives.

Why Seven Star LLC?

Seven Star LLC supplies genuine Autonics sensors and automation components to customers in Oman and the GCC. We verify model codes, ensuring the correct encoder resolution and output type for your application.

Our engineers help you verify the exact model and revision before ordering, avoiding mismatches and delays.

Reading the Autonics Model Code

Autonics encoder part numbers describe the unit completely, so the fastest way to confirm a replacement is to read the label on the installed encoder and compare it field by field. In this code, E40S is the series with a 40 mm body and solid shaft, the following 6 indicates the shaft diameter, 2500 is the resolution in pulses per revolution, and the remaining fields describe the output phases, the output circuit and the supply voltage. Before ordering the Autonics E40S6-2500-6-L-5 encoder as a like-for-like spare, check that every field on the old label matches, especially the output circuit and supply voltage, because a 5 V line-driver unit and a 12–24 V open-collector unit are not interchangeable at the controller input.
