Zebra ZT421 6-Inch Industrial Label Printer

Name: Zebra ZT421 6-Inch Industrial Label Printer – Datasheet & Quote
Brand: Zebra Technologies
SKU: ZT421

The Zebra ZT421 is the wide-format member of the ZT400 industrial printer series. Where the ZT411 stops at 4.09 in., the ZT421 prints up to 6.6 in. (168 mm) wide, which suits large shipping and pallet labels, equipment data plates, drum and chemical hazard labels and tags with several barcodes or graphics.

Wide labels without a larger machine class

Both ZT400 models use the same operating concept: a metal print mechanism, side-loading media path, 4.3 in. colour touch display, ARM Cortex A7 processor, 256 MB RAM and 512 MB Flash, Link-OS and thermal transfer or direct thermal printing. Door and mechanism lights illuminate the supplies path, and the printhead and platen can be replaced without tools.

The wide platform handles media web widths from 2.00 in. (51 mm) to 7.0 in. (178 mm) in tear and cutter modes and up to 6.75 in. (171 mm) in peel and rewind modes, with ribbon from 2.00 to 6.85 in. (174 mm). Resolution is 203 dpi (8 dots/mm) or 300 dpi (12 dots/mm); the ZT421 specification does not list 600 dpi.

Technical specifications

Parameter	Specification
Print methods	Thermal transfer and direct thermal
Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Maximum print width	6.6 in. (168 mm)
Print speed	203 dpi: 2.4 to 12 in./s (61 to 305 mm/s); 300 dpi: 2.4 to 10 in./s (61 to 254 mm/s), 1 in. increments
Maximum continuous print length	102 in. (2591 mm) at 203 dpi; 45 in. (1143 mm) at 300 dpi
Maximum non-continuous label length	39 in. (991 mm)
Media types	Continuous, die-cut, notch, black-mark
Media thickness	0.0023 in. (0.058 mm) to 0.010 in. (0.25 mm)
Maximum roll	8.0 in. (203 mm) O.D. on 3 in. (76 mm) I.D. core
Ribbon	2.00 in. (51 mm) to 6.85 in. (174 mm) wide; 450 m maximum length
Languages	ZPL, ZPL II, EPL, XML-enabled printing; ZBI 2.0 optional
Standard interfaces	USB 2.0, RS-232, 10/100 Ethernet, Bluetooth 4.1, dual USB host
Options	Parallel, dual-radio 802.11ax Wi-Fi/Bluetooth 5.3 or 802.11ac/Bluetooth 4.2, applicator interface, cutter, peel, rewind, UHF RFID encoder, ZKDU keyboard display
Operating environment	Thermal transfer 5 to 40 C, direct thermal 0 to 40 C, 20 to 85 percent non-condensing
Power	Auto-detecting 100-240 VAC, 50-60 Hz, ENERGY STAR qualified
Safety and EMC (as printed)	IEC 62368, Class B, EN 55032, EN 55035, EN 61000-3-2, EN 61000-3-3

Sensing, media handling and software

Dual transmissive and reflective sensors adjust from 0.06 in. to 4.31 in. from the inside media edge, which covers the wider web. The sheet gives gap (2 to 4 mm), notch (6 mm by 3 mm) and hole (3 mm) standards and a black-mark length of 2.5 to 11.5 mm with at least 9.5 mm width. Rewind internally rewinds a full roll on a 3 in. core or peels and rewinds liner, and the front-mount cutter works under software control (not with rewind or peel).

ZPL II and EPL are resident, and the Link-OS operating system supports Zebra DNA tools for configuration and monitoring. Printhead element-out detection and print-quality alerts help maintenance planning on long labelling lines.

Choosing between the ZT411 and ZT421

Choose the ZT421 when the label or tag is wider than 4.09 in., or when a 6.6 in. print area replaces two narrow passes. If every label fits within 4.09 in., the ZT411 is the narrower alternative and offers a 600 dpi option. Confirm resolution, interfaces, finishing options, cord type, and the media and ribbon material before ordering. Related equipment is shown under industrial automation accessories.

Documents and quotation

The Zebra ZT421 specification sheet (manufacturer PDF) is attached to this page. Send label size, daily volume, media type and delivery location through the request form for a quotation from Seven Star LLC, an independent supplier in Muscat.

Printer families

The industrial range covers the ZT111, ZT231, ZT400, ZT510 and ZT600 series, with print widths up to 6.6 in., resolutions up to 600 dpi and ZPL programming. Desktop models such as the ZD421 and ZD621 serve stores, laboratories and dispatch desks, while the ZE500 print engines are designed for label applicators. The printers run the Link-OS operating system, and RFID encoding is available on selected models.
