Brand: Böhler Welding
Böhler Thermanit 22/09 ER2209 Duplex TIG Welding Rod
Description
ER2209 TIG rod for 2205 duplex stainless steel
Böhler Thermanit 22/09 is a solid TIG rod of type ER2209 / W 22 9 3 N L designed for welding 2205 duplex stainless steel. Böhler Welding states resistance to intercrystalline corrosion and to wet corrosion up to 475 °F, good resistance to stress corrosion cracking in chloride and hydrogen-sulphide bearing environments, and high resistance to pitting from the Cr and Mo contents. It is used for joining and surfacing with matching and similar duplex steels and cast grades, so it is a rod for duplex piping, pressure vessels and heat exchangers in oil, gas, desalination and chemical plants.
Technical specifications
| Parameter | Specification |
|---|---|
| AWS classification | A5.9 / SFA-5.9 ER2209 |
| EN ISO classification | 14343-A W 22 9 3 N L |
| Typical analysis, wt % | C 0.02; Si 0.4; Mn 1.7; Cr 22.5; Ni 8.8; Mo 3.2; N 0.15 |
| All-weld metal, as welded (typical, minimum) | Yield 87 ksi (600 MPa), min 65; tensile 104 ksi (717 MPa), min 80; elongation 33 %, min 20 |
| Impact energy | 74 ft-lbf at 68 °F; above 35 ft-lbf at -40 °F |
| Sizes (length 39 in.) and parameters | 5/64 in.: 100-130 A, 14-16 V; 3/32 in.: 130-160 A, 16-18 V; 1/8 in.: 160-190 A, 18-20 V |
| Approvals | TÜV (03343), ABS, DNV GL, LR, NAKS, CE |
Duplex welding practice and selection
Duplex stainless steel keeps its balance of ferrite and austenite only when heat input, interpass temperature and cooling rate stay within the procedure window, and the data sheet warns that attention must be paid to embrittlement susceptibility of the parent metal. Argon back purging, strict cleanliness and a PMI check on finished welds are normal. For austenitic grades use
or . For submerged arc welding of duplex, lists the Thermanit 22/09 SAW wire among its typical combinations.| Related Böhler TIG rod | AWS / EN ISO class | Typical use |
|---|---|---|
| Thermanit JE-308L | ER308L / W 19 9 L | Stainless 304 and 304L |
| Thermanit GE-316L | ER316L / W 19 12 3 L | Stainless 316 and 316L |
| Thermanit 309L | ER309L / W 23 12 L | Dissimilar joints and buffer layers |
Handling and what to confirm
Store duplex rods clean and dry, apply argon back purging on the root, and monitor interpass temperature. Welds should be tested for ferrite balance and, in corrosive service, for corrosion resistance if the specification asks for it. Confirm diameter, pack size, certificate level and any NACE or ASTM A923 test requirement when ordering.
Documents and quotation
The Böhler Welding data sheet for Thermanit 22/09 (GTAW, US edition) is attached. Browse the TIG Welding Wire category for more. For a quotation, send diameter, pack size, quantity and certificate requirements, and state any NACE or corrosion test requirement.
Datasheets & Documents
- Datasheet Böhler Welding Thermanit 22/09 GTAW product data sheet (US edition) Download
Reviews (0)
About brand
Böhler Welding is the welding consumables brand of voestalpine Böhler Welding, part of the voestalpine group, with a portfolio that covers stick electrodes, TIG rods, solid wires, gas-shielded and self-shielded flux-cored wires and submerged-arc wires and fluxes. The company states more than 100 years of experience. Seven Star LLC, an independent supplier in Muscat, lists Böhler Welding consumables and welding machines, including pipeline electrodes, and sources Böhler Welding consumables for fabricators and pipeline contractors.
Böhler Welding product groups
Beyond the consumables above, Böhler Welding lists strip cladding, wire arc additive manufacturing, metal powders, arc spraying cored wires, ceramic weld backing, brazing consumables and welding automation such as orbital welding and collaborative robots. The pipeline range includes cellulosic FOX CEL electrodes and basic vertical-down FOX BVD electrodes for large-diameter line pipe.
Ordering Böhler Welding consumables: what we need
Give the product name, the AWS or EN classification, the diameter and length, and the packaging you need. For pipeline electrodes also state the pipe grade, wall thickness, welding position and whether sour-service test values are required, because the Böhler Welding data sheets note that some test values are available on request.
Related products
Frequently Asked Questions
What is the classification of Thermanit 22/09?
AWS A5.9 ER2209 and EN ISO 14343-A W 22 9 3 N L.
Which steel is it designed for?
2205 duplex stainless steel and matching duplex cast grades.
What nitrogen and molybdenum content is typical?
About 0.15 % nitrogen and 3.2 % molybdenum.
What impact energy does the data sheet give?
74 ft-lbf at 68 °F and above 35 ft-lbf at -40 °F.
Which approvals are printed?
TÜV (03343), ABS, DNV GL, LR, NAKS and CE.
